Panduit faceplate CFPUKS2SIWY 2 hole + modular panduit cat 6 Blue CJ688TPBU
Rp242.424
Deskripsi
Spesifikasi faceplate CFPUKS2SIWY 2 hole
| Product Type | Faceplate |
| Number of Ports | 2 |
| Module Type | Mini-Com® |
| Sub Brand | Pan-Net® |
| Material | ABS |
| Color | Off White |
| Identification Type | Label Pocket |
| Outlet Orientation | Sloped Shuttered |
| Overall Width (In.) | 3.39 |
| Overall Width (mm) | 86.1 |
| Overall Depth (In.) | 0.94 |
| Overall Depth (mm) | 23.87 |
| Overall Height (In.) | 3.39 |
| Overall Height (mm) | 86.1 |
| Gang Opening Type | Single Gang |
| Standards Met | RoHS Compliant |
Spesifikasi Mini-Com® UTP RJ45 Cat 6 TP-Style Jack Module, Blue
| Product Type | Jack Module |
| Performance Level | Category 6 |
| Connector Type | Jack Module |
| Termination Style | TP Style |
| Body Material | ABS |
| Contact Material | Plated Phosphor Bronze |
| Module Type | Mini-Com® |
| Wiring Scheme | T568A/T568B |
| Shield Type | Unshielded (UTP) |
| Sub Brand | Pan-Net® |
| Maximum Operating Temperature (°C) | 65 |
| Maximum Operating Temperature (°F) | 149 |
| Minimum Operating Temperature (°C) | -10 |
| Minimum Operating Temperature (°F) | 14 |
| Maximum Storage Temperature (°C) | 70 |
| Maximum Storage Temperature (°F) | 158 |
| Minimum Storage Temperature (°C) | -40 |
| Minimum Storage Temperature (°F) | -40 |
| Resistance Properties | Heat-Resistant |
| Color | Blue |
| Standards Met | Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant. |
| Overall Depth (In.) | 1.43 |
| Overall Depth (mm) | 36.3 |
| Overall Height (In.) | 0.71 |
| Overall Height (mm) | 18 |
| Overall Length (In.) | 1.43 |
| Overall Length (mm) | 36.3 |
| Overall Width (In.) | 0.63 |
| Overall Width (mm) | 16 |
